מגבר סטריאו משולב NORMA AUDIO REVO IPA – 80

SPECIFICATIONS:

• Inputs: 1 Phono MM/MC (optional), 4 Line RCA, 1 Direct (AV) IN
• Inputs Impedance: 10 Kohm
• Outputs: 1 REC OUT, 2 pair of Main Speakers Outputs,
• Phono: MM / MC,
• Phono Input Impedance: 47 Kohm, 1 Kohm, 500 Ohm. 100 Ohm, Spare
• Phono Gain: 34 dB, 38 dB, 42 dB, 46 dB, 50 dB, 52 dB, Spare
• Speaker outputs: 2 pair main output
• Frequency Response: 0-800 KHz  (Volume at MAX)
• Configuration: Solid state
• Output Power: 80 W RMS / 8 Ohm – 150W RMS / 4 Ohm (each channel)
• Outputs Current : 24 A continuous, 100 A peak (each channel)
• Electric transformer: toroidal special audio use, 300 VA
• Gain Sensitivity: 34 dB, 470 mV for  80 W / 8 Ohm
• Supply: 230 V AC / 50 Hz, (100V AC or 115 VAC / 50-60Hz in some countries)
• Dimensions (HxWxD): 75 x 430 x 350 mm
• Weight: 16 Kg

Sensitivity: 34 dB, 470 mV for 70 W / 8 Ohm

Supply

230 V AC / 50 Hz, (100V AC or 115 VAC / 50-60Hz in some countries)

Dimensions (HxWxD)

Solid state

Weight

15 Kg

Note

Integrated amplifier with full remote control by NORMA IR
